FKM Rubber sheet are the well-known high- performance rubber that has excellent resistance to hydrocarbons, chemicals, oil and heat.  It shows excellent resistance to heat, oil and strong acid or alkaline. It also has outstanding resistance to compression, especially at elevated temperatures. This rubber sheeting is widely used in oil industry, aviation field, automotive industry, aerospace and other aggressive environments

Features
Excellent chemical resistance.
Outstanding heat resistance.
Excellent sealing capability in aggressive environments.
Excellent compression set resistance.
Excellent UV & ozone resistance.
Resistant to liquid permeation in severe conditions.
Good resistance to flame.

FKM RUBBER SHEET

CODE

SPECIFICATION

HARDNESS
SHOREA

S.G.
G/CM3

TENSILE STRENGTH
MPA

ELONGATION
AT BREAK %

COLOUR

JD-FK75205

FKM

75

2.05

5

165%

Black/Blue

JD-FK75195

FKM

75

1.95

7

165%

Black/Blue

JD-VT75180

VITON

75

1.81

8.5

175%

Black/Blue



Standard Width

0.915m upto 1.5m

Standard Length

10m-20m

Standard Thickness

1mm upto 100mm 1mm-20mm in roll

20mm-50mm in sheet

Custom sizes available upon request.
