High-voltage insulating rubber mats are critical safety barriers in power distribution rooms and switchgear areas. As polymer-based materials, they gradually degrade over time due to service duration, UV exposure, temperature and humidity cycles, as well as mechanical stress. Many forms of aging are not visually obvious, yet once insulation performance deteriorates, the risk of electric shock rises sharply. It is essential for operation and maintenance personnel to master aging identification methods, conduct regular inspections, and replace degraded mats in a timely manner.
1. Visible Aging Signs for On-Site Inspection
Hardening and Brittleness — The mat loses its original elasticity and becomes rigid. Surface whitening appears when bent; continued stress leads to crack initiation.
Cracking — Fine crazing or edge cracks emerge on the surface. Cracks propagate inward and directly compromise the insulation structure.
Delamination, Blistering and Peeling — Separation between the top rubber layer and the backing, accompanied by blisters or flaking, indicates severe aging.
Chalking and Discoloration — The surface fades noticeably and rubber powder rubs off when wiped by hand.
Physical Damage — Scratches, indentations or punctures on the surface. Even minor defects significantly reduce dielectric withstand capability.
2. Hidden Aging Beyond Visual Inspection
Intact appearance does not guarantee acceptable insulation performance. Long-term environmental attack breaks down the internal polymer structure and lowers the breakdown voltage.
Note: Some mats show no surface damage at all. Once they reach the end of their service life, they must undergo withstand voltage testing before any high-voltage deployment.
＞send emails to sales@jingdongrubber.com,get a quote now
3. Inspection Procedures and Scrapping Criteria
Daily Walk-Down Inspection — Visually examine each mat before every operation.
Periodic Testing — Submit mats to accredited third-party laboratories for withstand voltage testing at intervals prescribed by applicable standards.
Scrapping Rule — If any serious surface defect is observed, or if the withstand voltage test fails, the mat must be removed from service immediately and must not be used at any power site.
4. Common Misconceptions
Myth: As long as there are no holes, the mat is safe to use.
Fact: Internal aging degrades insulation even when the surface appears flawless.
Myth: Minor cracks do not affect insulation performance.
Fact: Cracks continue to propagate and may cause dielectric breakdown under high voltage, leading to safety incidents.
Myth: Aged or damaged mats can be repaired and reused.
Fact: High-voltage insulating rubber mats cannot be patched or refurbished; damaged units must be replaced.
Conclusion
Operation and maintenance teams should establish a routine inspection regime that combines visual walk-downs with professional withstand voltage testing. Timely identification of aging signs and prompt removal of non-compliant mats are fundamental to ensuring electrical safety on site.
