As an important industrial protective material,the core value of a heat proof rubber mat lies in its outstanding high-temperature resistance achieved through special formula design and production processes.From the selection of raw materials to the final product,the entire process embodies breakthroughs in materials science and the wisdom of precision manufacturing.
In terms of basic composition,silicone rubber is one of the mainstream base materials.
Experimental data shows that when the proportion of silicone rubber in the formula reaches 85-95 parts,和 10-15 parts of graphite powder and 6-10 parts of mica powder are added as modified components,the thermal stability of the material can be significantly improved.This composite structure takes advantage of the excellent heat insulation properties of layered mineral fillers-the physical barrier formed by mica sheets can effectively block heat conduction,while flake graphite disperses local heat accumulation quickly through its high thermal conductivity.The combined effect keeps the rubber matrix intact when exposed to heat.Notably,some high-end products also use fluororubber as a reinforcing phase.The C-F bonds in the molecular chains of these fluoropolymers have extremely high bond energy,giving the material a breakthrough temperature resistance limit.Some special formulas can even withstand continuous high temperatures above 250°C.
The production process also plays a crucial role in performance.
Modern factories generally adopt a stepwise mixing process:第一的,天然橡胶,styrene-butadiene rubber,or ethylene propylene diene monomer(三元乙丙橡胶)和其他主要材料最初与碳黑色和无机填充剂混合,然后是抗衰老剂,加速器,和其他添加剂逐渐添加用于辅助精炼。此阶段的温度控制特别精确,确保所有组件都是完全集成的，同时避免了过早的交联反应.
＞将电子邮件发送到sales@jingdongrubber.com,立即获取报价
成型阶段通常使用自定义模具进行压缩硫化,with process parameters set for dynamic balance-maintaining the temperature between 140°C and 170°C,combined with a pressure field of 10-20 MPa.This not only promotes the orderly arrangement of rubber molecular chains but also prevents excessive flow that could cause dimensional deviations.Especially the precise timing of the vulcanization stage directly affects the product’s compression set and elastic recovery rate.
辅助材料的创新应用正在不断扩大产品边界.
例如,在耐热和耐腐蚀的公式中,工程师创造性地将氧化镁和氢氧化钙引入酸碱缓冲液系统,combined with bisphenol AF-type antioxidants to build a multi-layered protection mechanism.These additives not only improve the rubber’s stability in highly corrosive environments but also avoid stress concentration problems caused by traditional fillers through micro-nano dispersion technology.For applications requiring special functions,the formula ratios are adjusted accordingly:insulating gaskets for the power industry that pursue ultimate insulation performance will enhance the proportion of natural rubber,while equipment seals that prioritize mechanical strength will increase the content of nitrile rubber to take advantage of its excellent wear resistance.
Quality control runs through the entire production process.
Each batch of raw materials must undergo strict physical and chemical tests to ensure that the particle size distribution of graphite meets the design requirements and the purity of mica powder is up to standard.The mixed rubber compound needs to be sampled and tested for Mooney viscosity,which is an important indicator of processing performance.Semi-finished products after molding must undergo aging tests under simulated working conditions,including periodic high-temperature exposure and cold-hot shock cycles.The final products must pass multiple physical property tests such as tensile strength,tear strength,and Shore hardness,as well as specialized tests such as insulation resistance and voltage resistance,before they can be approved for release.
With the iterative upgrading of industrial technology,new nanomodification technologies have begun to be applied in the field of heat proof rubber mats.
Researchers have found that uniformly dispersing a small amount of carbon nanotubes in the rubber compound can enhance thermal conductivity without reducing flexibility;while surface-modified silica particles can form a three-dimensional network structure,effectively inhibiting molecular chain segment movement at high temperatures.These microscopic innovations are reshaping the performance boundaries of traditional products,providing more reliable solutions for cutting-edge fields such as aerospace and new energy.
